XH-8256C DMX 256 Controller
Detail Info
DMX 256 Controller
● DMX512/1990 standard, up to 256 DMX control channels, one optical isolation signal output.
● Maximum control of 16 computer lights / 64 channels of dimming.
● Automatically generate the light library
● LCD display with backlight, the first Chinese and English display switchable interface. The panel is available in English and Chinese.
● Built-in graphic track generator, with 35 built-in graphics, convenient for users to control the graphics of the computer lights, such as drawing circles, spirals, rainbows, chasing and other effects.
● Graphic parameters (such as amplitude, speed, interval, wave, direction) can be set independently, making it easier and faster to make the desired shape and scene.
● It can store 80 replay scenes for storing multi-step scenes and single-step scenes. Each multi-step scene can store up to 600 single steps.
● 16 replay scenes can be output and run simultaneously.
● With 16 centralized push rods. Key point control and fader control are compatible.
● The data can be memorized and maintained during shutdown / sudden power failure.
● The U disk can back up the console data and support re-importing to the console. The same model console data can be shared.
● Support remote software upgrades, adding new features anytime, anywhere.
● Preset fader can control the properties of the computer light, and the property control is more convenient and quick.
● Support immediate black field
● Product size: 480x220x75
● Net weight: 3.7KG
● Power supply: AC 100 -240V / 50-60Hz.
● Maximum control of 16 computer lights / 64 channels of dimming.
● Automatically generate the light library
● LCD display with backlight, the first Chinese and English display switchable interface. The panel is available in English and Chinese.
● Built-in graphic track generator, with 35 built-in graphics, convenient for users to control the graphics of the computer lights, such as drawing circles, spirals, rainbows, chasing and other effects.
● Graphic parameters (such as amplitude, speed, interval, wave, direction) can be set independently, making it easier and faster to make the desired shape and scene.
● It can store 80 replay scenes for storing multi-step scenes and single-step scenes. Each multi-step scene can store up to 600 single steps.
● 16 replay scenes can be output and run simultaneously.
● With 16 centralized push rods. Key point control and fader control are compatible.
● The data can be memorized and maintained during shutdown / sudden power failure.
● The U disk can back up the console data and support re-importing to the console. The same model console data can be shared.
● Support remote software upgrades, adding new features anytime, anywhere.
● Preset fader can control the properties of the computer light, and the property control is more convenient and quick.
● Support immediate black field
● Product size: 480x220x75
● Net weight: 3.7KG
● Power supply: AC 100 -240V / 50-60Hz.
